HVAC Clamp Meter
Description
Call for Pricing!
Additional information
| Special Features | Automatically Ranging True Root Mean Squared (TRMS) Measurement Technology for Accuracy; NCVT; V + A Simultaneously Displayed; Built-in Worklight |
|---|---|
| DC Polarity Indicator | Yes |
| Batteries | 3 x AAA |
| Auto-Power Off | Yes |
| Material | ABS/Electronics |
| Overall Height | 1.59" (4 cm) |
| AC Voltage | 750V |
| Included | Clamp Meter; Right-Angle Input Test Leads; Push-On Alligator Clips; K-Type Thermocouple; Storage Pouch; Instruction Manual; and 3 x AAA Batteries |
| Ohms (Resistance) | 60MΩ |
| Standard | CAT IV 600V, CAT III 750V, Class 2, Double Insulation Safety Rating |
| Weight | 12.5 oz (355 g) |
| Current | 600A |
| DC Voltage | 600V |
| Voltage | 750V AC; 600V DC |
| Type | HVAC TRMS Clamp Meter |
| Display | 6000 Count LCD |
| Drop Protection | 6.6' (2 m) |
| Capacitance | 6.000mF |
| Overall Length | 9.24" (23.5 cm) |
| Temperature Range | -148° to 1832°F (-100° to 1000°C) |
| Application | Measures AC Current, Inrush Current, AC/DC Voltage, DC Microamps, Resistance, Continuity, Frequency, Capacitance, Temperature, Diodes, and More |
| DC Micro-Amp | 600µA |
| Overall Width | 3.77" (9.6 cm) |
| Ingress Protection | — |
| Frequency | 60 kHz |
| UPC | 92644693786 |
| UNSPSC | 41113654 |
