Advanced Electrical Circuit Breaker Finder and Wire Tracer Kit and Case
Description
Call for Pricing!
Additional information
| Included | Transmitter, Receiver, Blade and Ground Prongs, Alligator Clips, 3' and 20' Lead Adapters, AC Plug Leads, Instructions, All Required Batteries, and Hard Carrying Case |
|---|---|
| Application | Trace Energized and Non-Energized Breakers, Fuses, and Wires |
| Overall Height | Receiver: 1.84" (4.5 cm); Transmitter: 1.51" (3.9 cm) |
| Overall Width | Receiver: 3.90" (9.9 cm); Transmitter: 2.07" (5.3 cm) |
| Standard | CAT III 600V |
| Weight | Transmitter: 16.5 oz (470 g); Receiver: 11 oz (312 g) |
| Material | ABS and Electronic Components |
| Lead Length | 3' (1 m) and 20' (6.1 m) |
| Type | Circuit Tracer |
| Drop Protection | 6' (2 m) |
| Voltage | External Indicators for 12V, 48V, 120V, 240V, and 480V |
| Overall Length | Receiver: 7.05" (17.9 cm); Transmitter: 8.72" (22.2 cm) |
| Special Features | Flashlight and NCV Function on Receiver; Accessories, and Hard Case |
| Ingress Protection | IP42 |
| Display | Receiver: LCD with Backlight |
| Tests Continuity | No |
| Frequency | Transmitter: AC 45Hz to 65Hz; Receiver: 33kHz |
| Interchangeable Leads | Yes |
| Batteries | Transmitter: 6 × 1.5V AA Alkaline; Receiver: 4 × 1.5V AA Alkaline |
| Integral Lead Storage | No |
| Pollution Degree | 2 |
| Control Type | Transmitter and Receiver |
| Case Included | Yes |
| Battery Life | Up to 24 hr |
| Battery Type | AA Alkaline |
| UPC | 92644693380 |
| UNSPSC | 41113637 |
