Rechargeable Thermal Imaging Camera
$314.99
Description
The Klein Tools TI250 is an easy-to-use, USB rechargeable Thermal Imager. The large LCD displays unseen hot and cold spots for instant troubleshooting. Excellent resolution with over 10,000 pixels and your choice of three color palettes. The meter provides high and low temperature points, crosshairs to pinpoint specific temperatures, and options for temperature alarms. The addition of an optional microSD® Card (sold separately) allows the meter to capture and store images for reporting.
Brochure
Instructions
MSDS
Feature
- Thermal Imager has over 10,000 pixels to troubleshoot hot and cold spots
- Adjustable emissivity from 0.01 to 1.00
- Store and share images with optional microSD® Card (sold separately)
- User selectable high and low temperature alarms from -4 to 752-Degree Fahrenheit (-20 to 400-Degree Celsius)
- Select color palettes to best capture the event
- Rechargeable lithium-ion battery
- Includes thermal imager, micro-USB charging cable, carrying case, and instructions
Warning
- Read, understand and follow all instructions, cautions and warnings attached to and /or packed with device before each use.
- Never use on or near live electrical circuits. NOT insulated. Will NOT protect against electrical shock.
Additional information
| Accuracy | At More Than 212°F (100°C): +/- 2° or 2% (Whichever is Greater); At Less Than 212°F (100°C): +/- 3° or 3% (Whichever is Greater) |
|---|---|
| Material | ABS/PC, Electronic Components |
| Display Resolution | 320 x 240 Pixels |
| Application | View Hot and Cold Spots For Instant Troubleshooting |
| Type | Thermal Imager |
| Standards | CE and UKCA |
| Emissivity | 0.01 to 1.00, Adjustable |
| Memory | MicroSD® Card (not included) |
| Field of View | 50° +/- 3° |
| Color Palettes | Ironbow, Rainbow, and Grayscale |
| Weight | 8.5 oz (241 g) |
| Spectral Range | 8 to 14μm |
| Sensor Type | VOx Microbolometer |
| Overall Width | 1" (2.5 cm) |
| Display | 2.4" (6.1 cm) TFT LCD |
| Included | Rechargeable Thermal Imager, Micro-USB Charging Cable, Carrying Case, and Instructions |
| Temperature Range | -4° to 752°F (-20° to 400°C) |
| Overall Length | 3.1" (8.0 cm) |
| Sensor Resolution | 10, 800 Pixels |
| Special Features | High and Low Temperature Points, Crosshairs to Pinpoint Specific Temperatures, Options for Temperature Alarms, 3 Color Pallets |
| Batteries | Lithium-Ion |
| Overall Height | 3.1" (8.0 cm) |
| Photo Capture | Yes |
| Picture in Picture | — |
| Thermal Sensitivity | <60 mK |
| UPC | 092644692932 |
| UNSPSC | 41115321 |
