Digital Multimeter, TRMS Auto-Ranging, 600V, Temp
$57.72
Description
Klein Tools MM420 Multimeter is an auto-ranging, true root mean square (TRMS) multimeter that measures AC/DC voltage, AC/DC current, and resistance. It can also measure temperature, capacitance, frequency, duty-cycle, and test diodes and continuity. Klein Tools’ Test and Measurement product line was exclusively designed from the ground up by electricians for electricians. Years of field research, combined with extensive input from electricians across America, inspired the development of meters and electrical testers loaded with innovative, time-saving features.
Brochure
Instructions
MSDS
Feature
- Multimeter with automatic ranging true root mean square (TRMS) technology for increased accuracy
- Measures up to 600V AC/DC voltage, 10A AC/DC current and 50 MOhms resistance, continuity, temperature, capacitance, frequency, duty-cycle, and test diodes
- Lead Alert protection with LED illumination for lead placement and an easy-to-view backlit display
- Low battery indicator and easily accessible battery and fuse compartment
- Durable meter built to withstand a 6.6-Foot (2 m) drop
- Includes test leads, thermocouple with adapter, batteries and user manual
- CAT III 600V safety rating
- For use in basic and controlled electromagnetic environments such as residential, business and light-industrial locations
Warning
- Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
- Do not use the meter during electrical storms or in wet weather, and do not use the meter or test leads if they appear to be damaged.
- Before each use verify meter operation by measuring a known voltage or current.
Additional information
| Ingress Protection | — |
|---|---|
| Standard | CAT III 600V; CE and UKCA Certified |
| Special Features | Lead-Alert; Auto-Range; Min/Max Measurements; Backlight; Auto Power-Off; Data-Hold |
| Overall Height | 1.78" (4.5 cm) |
| Included | Multimeter, Test Leads with CAT III/CAT IV Safety Caps, Thermocouple, Instructions, 2 x AAA Batteries |
| Voltage | 600V AC/DC |
| Overall Length | 6.41" (16.2 cm) |
| Weight | 8.2 oz (231 g) |
| Package Quantity | — |
| Ohms (Resistance) | 50MΩ |
| Type | Digital Multimeter |
| Temperature Range | -40° to 1832°F (-40° to 1000°C) |
| Current | 10A AC/DC |
| Sub Brand | — |
| Frequency | 1 Hz – 50 KHz |
| Material | ABS, Electrical Components |
| Functions | Measures up to 600V AC/DC Voltage, 10A AC/DC Current, 50MΩ Resistance, Temperature, Capacitance, Frequency, Duty-Cycle, Test Diodes, and Continuity |
| Color | Orange/Black |
| Capacitance | 400 µF |
| Display | 4000 Count LCD |
| Application | Testing and Measuring Voltage |
| Batteries | 2 x AAA |
| Overall Width | 3.16" (8 cm) |
| Drop Protection | 6.6' (2 m) |
| Accuracy | See Instructions |
| UPC | 092644693748 |
| UNSPSC | 41113630 |
