AFCI /GFCI Outlet Tester
$41.97
Description
RT310 is an electrical tester that tests the wiring condition at an electrical outlet, and inspects and checks AFCI and GFCI devices. It is designed for use with North American 120V electrical outlets. It can detect and identify common wiring faults. Includes 3 x 1.5V AAA alkaline batteries.
Brochure
Instructions
MSDS
Feature
- GFCI Tester detects the most common wiring faults in standard, AFCI, and GFCI electrical outlets
- Test AFCI devices by simulating arc fault conditions
- Test GFCI devices by simulating ground fault conditions
- Capable of detecting a dual-open wiring fault with simultaneous open neutral and open ground wires (patent pending technology)
- Tester delivers clear visual indication of the wiring condition at the electrical outlet
- Designed to test North American-style grounded electrical outlets in 120V AC circuits (incorporates a three-pin plug)
- Electrical plug is on a 10-Inch (25.4 cm) flexible electrical cord to access electrical outlets in difficult to reach locations
- Low battery indicator and easily accessible battery compartment; Uses 3 x 1.5V AAA alkaline batteries (included)
- Powers off automatically after approximately 2 minutes of non-use to conserve battery life
- Built to withstand a 6.6-Foot (2 m) drop
Warning
- Read, understand, and follow all warnings and instructions before operating testers
- Before each use, verify tester operation by testing on a known live and correctly wired receptacle and circuit
- DO NOT use if the tester appears damaged in any way
- This tester only detects common wiring problems. DO NOT attempt electrical testing on an incorrectly wired outlet
- Always consult a qualified electrician to resolve wiring problems.
Additional information
| Special Features | Tests AFCI and GFCI, Simulates Ground Fault and Arc Flash Conditions, Detects Dual-Open Wiring Fault |
|---|---|
| GFCI | Yes |
| Material | PC/ABS Housing with Electronic Components |
| Voltage | 120V AC in 3-Wire Grounded Electrical Outlet |
| Weight | 8.5 oz (241 g) |
| Standard | CATIII 135V |
| Overall Width | 2.3" (5.8 cm) |
| Overall Height | 1.3" (3.3 cm) |
| Application | RT310 is an electrical outlet tester that tests for wiring faults in electrical outlets, and Tests AFCI and GFCI Devices |
| Drop Protection | 6.6' (2 m) |
| Type | AFCI/GFCI Electrical Battery Operated Outlet Tester |
| Overall Length | 7.4" (18.8 cm) |
| AFCI | Yes |
| Batteries | 3 x AAA |
| Included | Outlet Tester; 3 x 1.5V AAA Alkaline Batteries |
| Style_Name | AFCI/GFCI Receptacle Tester |
| Battery Type | Alkaline |
| UPC | 092644691829 |
| UNSPSC | 41113642 |
