AC Plug to Banana Jacks
$10.49
Description
The Klein Tools AC Plug to Banana Jacks accessory is compatible with products that have banana-type input jacks. Attach the Banana Jack connectors to the meter and easily plug into an outlet for measuring or tracing a circuit. They are part of a full line of Klein Tools meters and testers, designed by electricians for electricians.
Brochure
Instructions
Feature
- Standard banana-type inputs attach to the meter and the AC Plug connects to circuit for measuring or tracing a circuit
- Cable length is 2-Foot (61 cm) long
- For use on North American 120V electrical outlets only
- Safety rated: CAT III 1000V/CAT IV 600V safety rating
- Double Insulated
- Test cable is PVC insulated 18 AWG dual wires
- For use with the Advanced Circuit Tracer Kit (Cat. No. ET450) or any brand of meter with banana-type connectors
Warning
- Read, understand, and follow all warnings and instructions before operating testers.
- Before each use, verify tester operation by testing on a known live and correctly wired receptacle and circuit.
- Use personal protective equipment to prevent shock and arc blast injury where hazardous live conductors are exposed.
Additional information
| For Use With | Cat. No. ET450 Electrical Test Kit and any Model with Standard Banana-Type Inputs |
|---|---|
| Connector Type | Banana Plug |
| Type | AC Plug to Banana Jacks |
| Weight | 1.9 oz (54.4 g) |
| Included | One Cable with AC Plug for Outlet and Banana Jacks to Attach to Meter |
| Special Features | Compatible with any Brand of Meter with Banana-Type Connectors |
| Material | PVC and Berillium Copper |
| Application | Electrical Tracing or Testing |
| Overall Width | 0.33" (8.1 cm) |
| Overall Height | 13" (33 cm) |
| Overall Length | 0.33" (8.1 cm) |
| UPC | 092644693571 |
| UNSPSC | 39121435 |
