HVAC Electrical Test Kit

Description

Klein Tools HVAC Electrical Test Kit features Cat. No. CL320 Auto-Ranging, TRMS (True Root Mean Square), 400A HVAC Clamp Meter; Cat. No. IR07 Dual IR and Probe Thermometer, for both surface and air temperature measurements; and Cat. No. NCVT3P Dual Range Non-Contact Voltage Tester With Flashlight, for detection of AC voltage from 12 to 1000V with visual and audible indicators. Included is a convenient carrying pouch, test leads with CAT III/CAT IV safety caps, thermocouple, and all batteries.

Brochure

Brochure 1

Brochure 2

Brochure 3

Instructions

Instructions 1

Instructions 2

Instructions 3

MSDS

MSDS 1

YouTube Video

Click Here to Download Video

Feature

1. HVAC Kit with testers for the HVAC Professional: HVAC Digital Clamp Meter, Dual IR/Probe Thermometer, and Dual Range Non-Contact Voltage Tester with Flashlight
2. Cat. No. CL320 HVAC Clamp Meter with TRMS technology measures AC current, NCVT, AC/DC voltage, resistance, frequency, DC microamps, capacitance, duty cycle, diode test, continuity, and temperature
3. Cat. No. IR07 Dual IR Probe and Thermometer measures temperature from -40 to 572 Degrees Fahrenheit (-40 to 300 Degrees Celsius); measure surface temperature with Infrared Thermometer (DS ratio 8:1)
4. Measure air vents and duct temperature using temperature probe with hands-free hanging hook; calculate differential temperature (T1-T2) for both IR and probe temperatures
5. Cat. No. NCVT3P is dual-range and detects from 12 to 1000 V AC or 70 to 1000V AC for a broad variety of low-voltage or standard voltage applications
6. Non-Contact Voltage Tester detects voltage with simultaneous visual and audible voltage indicators
7. Bright flashlight illuminates work area and may be used independent of voltage detection function; CAT IV 1000V rating provides expanded operation and protection
8. IR07 Thermometer is not a medical device and is NOT intended for use on people or animals

Warning

1. Read, understand and follow all instructions, cautions and warnings attached to and /or packed with all test and measurement devices before each use.
2. Do not attempt to measure resistance or continuity on live circuits.
3. Before each use verify meter operation by measuring a known voltage or current.
4. Usage of this meter in any way other than that specified by the manufacturer can impair safe operation, resulting in severe injury or death.
